Drive Axle for Forklift

Forklift Drive Axle - A lift truck drive axle is actually a piece of equipment that is elastically connected to a vehicle frame using a lift mast. The lift mast is attached to the drive axle and is capable of being inclined around the drive axle's axial centerline. This is accomplished by no less than one tilting cylinder. Frontward bearing components combined with rear bearing elements of a torque bearing system are responsible for fastening the vehicle and the drive axle framework. The drive axle could be pivoted round a swiveling axis oriented horizontally and transversely in the vicinity of the rear bearing parts. The lift mast is also capable of being inclined relative to the drive axle. The tilting cylinder is connected to the lift truck framework and the lift mast in an articulated fashion. This allows the tilting cylinder to be oriented nearly parallel to a plane extending from the swiveling axis to the axial centerline.

Forklift models like H35, H40 and H45 which are manufactured in Aschaffenburg, Germany by Linde AG, have the lift mast tilt ably affixed\connected on the vehicle framework. The drive axle is elastically affixed to the lift truck frame utilizing many bearing devices. The drive axle comprise tubular axle body together with extension arms attached to it and extend rearwards. This particular kind of drive axle is elastically connected to the vehicle frame using rear bearing parts on the extension arms along with frontward bearing devices situated on the axle body. There are two rear and two front bearing devices. Each one is separated in the transverse direction of the vehicle from the other bearing machine in its respective pair.

The drive and braking torques of the drive axle are maintained through the back bearing elements on the framework by the extension arms. The load and the lift mast create the forces which are transmitted into the roadway or floor by the frame of the vehicle through the drive axle's anterior bearing elements. It is important to ensure the elements of the drive axle are installed in a rigid enough manner so as to maintain stability of the forklift truck. The bearing elements could lessen small road surface irregularities or bumps all through travel to a limited extent and offer a bit smoother function.
